| 加工定制：否 | 品牌：SICK/施克 | 型号：WT100-N1419 |
| 种类：光电 | 材质：陶瓷 | 材料物理性质：半导体 |
| 材料晶体结构：单晶 | 制作工艺：集成 | 输出信号：开关型 |
| 防护等级：IP67 | 线性度：1 | 迟滞：2 |
| 重复性：1 | 灵敏度：1 | 漂移：1 |
| 分辨率：1 |
施克SICK光电传感器W100系列有以下型号：
| WS100-D3030 | WL100-P1339 | WS/WE100-N4439 | WL100-N1409 |
| WE100-N1432 | WL100-P1439 | WS/WE100-P4239 | WL100-N3409 |
| WE100-N3430 | WL100-N3239 | WS/WE100-P4339 | WL100-N4409 |
| WE100-P3430 | WL100-N3439 | WS/WE100-P4439 | WL100-P1409 |
| WS/WE100-N1232 | WL100-P3239 | WL100-N4430 | WL100-P3409 |
| WS/WE100-N1432 | WL100-P3339 | WL100-P4230 | WL100-P4409 |
| WS/WE100-P1232 | WL100-P3439 | WL100-P4330 | WS/WE100-N1409 |
| WS/WE100-P1432 | WT100-N1432 | WL100-N4239 | WS/WE100-N3409 |
| WS/WE100-N3230 | WT100-P1432 | WL100-N4339 | WS/WE100-N4409 |
| WS/WE100-P3230 | WT100-N3430 | WL100-N4439 | WS/WE100-P1409 |
| WS/WE100-P3430 | WT100-P3430 | WL100-P4239 | WS/WE100-P3409 |
| WS/WE100-N1239 | WT100-N1439 | WL100-P4339 | WS/WE100-P4409 |
| WS/WE100-N1439 | WT100-P1439 | WL100-P4439 | WT100-N1402 |
| WS/WE100-P1239 | WT100-N3439 | WL100-N4420 | WT100-N3400 |
| WS/WE100-P1339 | WT100-P3439 | WL100-P4420 | WT100-N4400 |
| WS/WE100-P1439 | WT100-N1412 | WL100-N4429 | WT100-P1402 |
| WS/WE100-N3239 | WT100-P1412 | WL100-P4429 | WT100-P3400 |
| WS/WE100-N3439 | WT100-N3410 | WT100-N4430 | WT100-P4400 |
| WS/WE100-P3239 | WT100-P3410 | WT100-P4430 | WL100-N1402 |
| WS/WE100-P3339 | WT100-N1419 | WT100-N4439 | WL100-N3400 |
| WS/WE100-P3439 | WT100-P1419 | WT100-P4439 | WL100-N4400 |
| WL100-N1232 | WT100-N3419 | WT100-P4410 | WL100-P1402 |
| WL100-N1332 | WT100-P3419 | WT100-N4419 | WL100-P3400 |
| WL100-N1432 | WL100-N1432S01 | WT100-P4419 | WL100-P4400 |
WT100-N1419：
| Features | |||
| Sensor/detection principle: | Photoelectric proximity sensor, Background blanking | |
| Dimensions (W x H x D): | 11 mm x 31 mm x 20 mm | |
| Housing design (light emission): | Rectangular, Slim | |
| Sensing range max.: | 4 mm ... 140 mm 1) | |
| Sensing range: | 10 mm ... 100 mm | |
| Type of light: | Visible red light | |
| Light source: | LED 2) | |
| Wave length: | 680 nm | |
| Light spot diameter (distance): | Ø 8 mm (90 mm) | |
| Sensitivity adjustment: | Potentiometer, 270° | |
| Focus adjustable: | - | |
